Report appendix samples

Chart pages from real reporting cycles

These excerpts are reproduced with client permission. Identifying details are anonymised. Each page corresponds to a section in our Monthly Facility Energy Report.

Hourly load curve chart with brass-toned annotation markers — Fig. 2-A · Hourly load profile with chiller start annotations (Hotel, 19 sub-meters)

Stacked bar chart comparing monthly consumption by building wing — Fig. 4-C · Wing allocation comparison, Jan–Mar 2026 (Mixed-use retail)

Peak demand timeline chart with demand charge exposure line — Fig. 3-B · Peak demand timeline and charge exposure (Medical clinic)

Tariff breakdown pie chart with engraved-style labels — Fig. 5-A · Tariff component breakdown (Municipal facility)

After-hours baseload Site anonymised

Fig. 6-D · After-hours baseload trend following corridor lighting schedule change

Printed meter register spreadsheet excerpt with serial numbers — Register excerpt · Meter audit deliverable (partial, serial numbers redacted)

Want charts like these for your building?

Tell us your meter count and building type. We will send a sample scope outline matched to your situation — not a generic brochure.

Request a quote
